All dimensions in inches. |
| Type |
Part No. |
Thread
Size |
A
Max. |
Min. Sheet
Thickness |
Hole Size
In Sheet
+.003
-.000 |
B
Max. |
C
Max. |
E
±.010 |
F
Max. |
L
Max. |
T
±.010 |
Min. distance
centre line hole
to sheet edge |
| Material |
Carbon
Steel |
Stainless
Steel |
| EB |
EBS |
440-1 |
4-40 |
.040 |
.040 |
.166 |
.150 |
.165 |
.250 |
.210 |
.335 |
.380 |
.190 |
| 440-2 |
.056 |
.056 |
| EB |
EBS |
632-1 |
6-32 |
.040 |
.040 |
.1875 |
.169 |
.187 |
.280 |
.230 |
.335 |
.380 |
.220 |
| 632-2 |
.056 |
.056 |
| EB |
EBS |
832-1 |
8-32 |
.040 |
.040 |
.213 |
.204 |
.212 |
.310 |
.280 |
.385 |
.440 |
.270 |
| 832-2 |
.056 |
.056 |
| EB |
EBS |
032-1 |
10-32 |
.040 |
.040 |
.250 |
.235 |
.249 |
.340 |
.280 |
.385 |
.440 |
.280 |
| 032-2 |
.056 |
.056 |
| EB |
EBS |
0420-1 |
1/4-20 |
.560 |
.560 |
.344 |
.305 |
.343 |
.430 |
.310 |
.500 |
.560 |
.340 |
| 0420-2 |
.090 |
.090 |
|
| |
| |
All dimensions in millimeters. |
| Type |
Part No. |
Thread
Size |
A
Max. |
Min. Sheet
Thickness |
Hole Size
In Sheet
+.003
-.000 |
B
Max. |
C
Max. |
E
±0.25 |
F
Max. |
L
Max. |
T
±0.25 |
Min. distance
centre line hole
to sheet edge |
| Material |
Carbon
Steel |
Stainless
Steel |
| EB |
EBS |
M3-1 |
M3x0.5 |
1 |
1 |
4.25 |
3.84 |
4.22 |
6.35 |
5.3 |
8.5 |
9.6 |
4.8 |
| M3-2 |
1.4 |
1.4 |
| EB |
EBS |
M4-1 |
M4x0.7 |
1 |
1 |
5.4 |
5.2 |
5.38 |
7.95 |
7.1 |
9.8 |
11.2 |
6.9 |
| M4-2 |
1.4 |
1.4 |
| EB |
EBS |
M5-1 |
M5x0.8 |
1 |
1 |
6.4 |
6.02 |
6.38 |
8.75 |
7.1 |
9.8 |
11.2 |
7.1 |
| M5-2 |
1.4 |
1.4 |
| EB |
EBS |
M6-1 |
M6x1 |
1.4 |
1.4 |
8.75 |
7.8 |
8.72 |
11.1 |
7.8 |
12.7 |
14.3 |
8.6 |
| M5-2 |
1.4 |
1.4 |
|
| ◎ Type EB are recommended for use in steel or aluminum sheet HRB 75~80 or less. |
| ◎ Type EBS are recommended for use in steel or aluminum sheet HRB 65~70 or less. |
