All dimensions in inches. |
| Type |
Part No. |
Thread
Size |
A
Max. |
Sheet
Thickness |
Hole Size
In Sheet
+.003
-.000 |
C
Max. |
H
Nominal |
Min. distance
centre line hole
to sheet edge |
| Material |
Stainless
Steel |
| EF |
256-1 |
2-56 |
.060 |
.060-.090 |
.172 |
.171 |
.188 |
.23 |
| 256-2 |
.090 |
.091-UP |
| EF |
440-1 |
4-40 |
.060 |
.060-.090 |
.172 |
.171 |
.188 |
.23 |
| 440-2 |
.090 |
.091-UP |
| EF |
632-1 |
6-32 |
.060 |
.060-.090 |
.213 |
.212 |
.250 |
.27 |
| 632-2 |
.090 |
.091-UP |
| EF |
832-1 |
8-32 |
.060 |
.060-.090 |
.290 |
.289 |
.312 |
.28 |
| 832-2 |
.090 |
.091-UP |
| EF |
032-1 |
8-32 |
.060 |
.060-.090 |
.312 |
.311 |
.343 |
.31 |
| 030-2 |
.090 |
.091-UP |
| EF |
0420-3 |
1/4-20 |
.120 |
.128-.155 |
.344 |
.343 |
.375 |
.34 |
| 0420-4 |
.151 |
.156-.186 |
| 0420-5 |
.182 |
.187-.UP |
|
| |
| |
All dimensions in millimeters. |
| Type |
Part No. |
Thread
Size |
A
Max. |
Sheet
Thickness |
Hole Size
In Sheet
+0.08
-0.00 |
C
Max. |
H
Nominal |
Min. distance
centre line hole
to sheet edge |
| Material |
Stainless
Steel |
| EF |
M2-1 |
M2x0.4 |
1.53 |
1.53-2.3 |
4.37 |
4.35 |
4.8 |
6 |
| M2-2 |
2.3 |
2.32-UP |
| EF |
M2.5-1 |
M2.5x0.45 |
1.53 |
1.53-2.3 |
4.37 |
4.35 |
4.8 |
6 |
| M2.5-2 |
2.3 |
2.32-UP |
| EF |
M3-1 |
M3x0.5 |
1.53 |
1.53-2.3 |
4.37 |
4.35 |
4.8 |
6 |
| M3-2 |
2.3 |
2.32-UP |
| EF |
M4-1 |
M4x0.7 |
1.53 |
1.53-2.3 |
7.37 |
7.35 |
7.9 |
7.2 |
| M4-2 |
2.3 |
2.32-UP |
| EF |
M6-3 |
M6x1 |
3.05 |
3.18-3.94 |
8.74 |
8.72 |
9.5 |
8.8 |
| M6-4 |
3.84 |
3.96-4.72 |
| M6-5 |
4.63 |
4.75-UP |
|
| ◎ Type EF recommended for use in steel or aluminum sheet HRB 65~70 or less. |
| ◎ The standard finish of EF is passivate. |
